PIG41U
Designed for latest Intel Core 2 Quad/Core 2 Duo Processors, Supports FSB 1333/1066/800 MHz
Specifications
| CPU | Support Intel Core 2 Due / Pentium D / Pentium 4 / Celeron D Socket LGA 775 package |
| FSB | 1066/800/533/400 MHz |
| Chipset | North Bridge Intel 945GC South Bridge Intel 82801 GB |
| VGA | VGA |
| Memory | DDR2 400/533/667 SDRAM |
| Slots | 1 X PCI Express x16 2 X PCI support 3.3V/5V PCI Bus interface |
| LAN | 10/100/1000 Fast Ethernet by Realtek RTL8100C |
| Audio | Realtek ALC655 5.1 channle audio out Vista Premium compliance |
| IDE | 1 X IDE port Ultra DMA 66/100/133, PIO & Bus Master operation mode |
| Back Panel I/O Ports | 1 X Serial Port compatible with high speed 16550 UARTmodel 1 X Parallel Port，support EPP/ECP/SPP transportaion 2 USB 2.0 1 X PS/2 Keyboard 1 X PS/2 Mouse 1 X VGA Port 3 audio jucks 1 LAN JACK |
| Internal I/O Connectors & Headers | 4 USB 2.0 pinheaders 1 Front Panel Audio pinheaders 1 CD-in connector |
| BIOS | support plug and play support Desktop Managment Interface(DMI) function which records mainboard specifications |
| Form Factor | ATX (24 cmX 16.8cm) |
| SATA | 2 SATA port controled by Intel 82801 North Bridge 2 SATA Devices Support storage and transfers up to 300MB/s |
