PIG31M
Designed for the latest Intel® Wolfdale, Core 2 Quad and Core 2 Duo / Pentium D/ Pentium 4/ Celeron D Processors,featuring the Intel® Bearlake G31 and ICH7 chipsets
Specifications
DDR2 800
2x 240-pin DDR2 DIMM sockets support up to 4GB (DDR2 667)
USB 2.0
USB 2.0 delivers transfer speed up to 480 Mbps, 40 times faster for easy connectivity and ultra-fast data transfers.
Onboard LAN
Provides Realtek 10/100 8101E PCIE Mbps solution to your network or broadband connection without having to buy an extra LAN card.
6 Channel Audio
Onboard audio CODEC supports uncompromising DVD audio quality, bringing about a more vivid sound sensation enabling high-quality audio without
buying other advance sound card.
PCI Express Slot
Delivers up to 4x increase in graphics and 2x I/O bandwidth for smooth multimedia performance.
BIOS
- AMI BIOS 8MB SPI ROM, supports Plug & Play 1.0A, APM1.2, Multi Boot, DMI.
- Full support for ACPI revision 1.0 specification.
| CPU | LGA775 socket for latest Intel Core 2 Quad/ Core 2 Duo / Pentium D / Pentium 4 / Celeron D processor |
| Chipset | Intel G31 & ICH7 - North Bridge: Intel G31 - South Bridge: Intel ICH7 |
| FSB | 1333/1066 Mhz |
| Memory | Dual-channel DDR2 memory architecture 2 x 240-pin DDR2 DIMM socket support up to 4 GB Support DDR2 667/800 DDRII SDRAM |
| VGA | Integated Intel Graphics Media Accelerator 3100 (GMA3100) Max Dynamic Video Memory:287MB(VISTA) /384MB(XP) |
| Expansion Slots | 1 x PCI ExpressX16 slot 1 x PCI ExpressX1 slot 2xPCI |
| LAN | Realtek 10/100 8101E PCIE LAN |
| Audio | Realtek ALC 662 6-channel HD Audio |
| IDE | 2xUltra DMA 100/66 Devices |
| Back Panel I/O ports | 1 x PS/2 keyboard/Mouse connectors 1 x VGA Port 4 x USB 2.0 Ports 1 x Audio port (Line-in, Line-out and Mic-in) 1 x COM Port 1 x RJ 45 Lan connector |
| Internal I/O Connectors | 24-pin ATX Power Supply connector and 4-pin 12v Connector 2 x USB header support additional 4 USB2.0 ports 1 x Front panel switch/LED header CPUFan / SYSFan connectors 1 x SPK header 1 x Floppy connector - supports 360K~2.88MB FDDS 1 x IDE connector 1 x Clear CMOS header 1 x SPDIF out header 4 x Serial ATA connector 1 x LPT header 1 x Front panel audio header 1 x CD_in header |
| Storage | Supported by Intel ICH7 2 x Ultra DMA 100/66 devices 4 x Serial ATA II devices |
| System BIOS | AMI BIOS with 8Mb SPI Flash ROM Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI Supports ACPI revision 1.0 specification |
| Form Factor | Micro ATX Form Factor, 244x200mm |
