PI865D7
Intel Pentium 4 (775 pins) with Dual Core CPU Support
Specifications
FSB 800
Supports INTEL latest 800MHz front side bus Pentium 4 CPU
10/100 LAN
Provides 10/100 Mbps solution to your network or broadband connection without having to buy an extra LAN card. (optional)
USB 2.0
USB2.0 is the latest connectivity standard which delivers transfer speeds up to 480Mb/s for easy connectivity and ultra-fast data transfers.
Dual DDR-400
Dual-channel DDR technology doubles the bandwidth of your system memory up to 6.4GB/s and boost the system performance
Serial-ATA
Serial ATA is the next generation ATA specification that provides scalable performance for today and tomorrow. With up to 150MB/s data transfer rate, Serial ATA is faster than current Parallel ATA, while providing 100% software compatibility
6-Channel Audio
Onboard 6-channel audio CODEC supports uncompromising DVD audio quality, bringing a more vivid sound experience and high-quality 6-channel audio without having to buy advanced sound cards
ATA100
Supports Ultra DMA 33/66/100 IDE devices, data transfer rate up to 100MB/s
| CPU | LGA775 socket for latest Intel Pentium 4/Celeron D processors/Pentium D processor |
| FSB | 800/533 MHz |
| Chipset | Intel 865GV/ICH5 |
| Graphic | Integrated Intel Extreme Graphics II |
| Memory | Dual-channel DDR memory architecture 2x 184-pin DDR DIMM socket support up to 2 GB Support DDR400/333/266 2.5V DDR SDRAM |
| Expansion Slots | 1 x AGP ultra 3 x PCI 1 x CNR |
| LAN | Realtek RTL8100C 10/100Mbps Faster Ethernet controller |
| Audio | RTL ALC655 6-channel audio Codec Compliant with AC97 2.3 specification |
| Storage | Support by Intel ICH5 4 x Ultra DMA100/66 devices　　　　　　　　　　　　　　 2 x Serial ATA devices　 |
| Back Panel I/O Ports | 1 x PS/2 keyboard 1 x PS/2 mouse 1 x Parallel Port 1 x Serial Port 1 x VGA Port 4 x USB 2.0 Ports 1 x RJ 45 Port 1 x Audio I/O (Line-in, Line-out and Mic-in) |
| Internal I/O Connectors & Headers | 20-pin ATX Power Supply connector 4-pin ATX 12V Power Supply connector 2 x USB header support additional 4 USB2.0 ports 2 x Serial ATA connectors 1 x Front panel switch/LED header 1 x Front panel audio header CPU / PWR/ SYS FAN headers 1 x IrDA for SIR header 1 x Speaker header 1 x CD in header 1xFloppy connector-support 360K~2.88M Byte, 3 Mode FDDs or LS120 |
| System BIOS | Award 4Mb Flash ROM Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI Full support for ACPI revision 1.0 specification |
| Form Factor | Micro-ATX Form Factor, 244*244mm |
