PIG41S
Support Intel Core 2 Extreme/Core 2 Quad /Core 2 Duo/Pentium Dual Core/Celeron Dual Core/Celeron in 775-pin
Specifications
| CPU | LGA775 socket for latest Intel Core 2 Quad /Core 2 Duo processors |
| Chipset | Intel® G41 and ICH7 Supports DirectX10. |
| FSB | 1333/1066/800 MHz |
| Memory | 2xDDR3 800/1066 MHZ SDRAM (8GB MAX)(M143D R1.0) 2xDDR2 667/800/1066 MHz SDRAM (4GB MAX) 2xDDR3 800/1066 MHz SDRAM (8GB MAX)(M148D R1.0) |
| LAN | Supports 10/100 Fast Ethernet by Realtek® RTL8100c or 8102EL Supports 10/100/1000 Fast Ethernet by Realtek® RTL8111DL(optional) |
| IEEE 1394(optional) | Chip integrated by VIA VT 6308 Transfer rate is up to 400Mbps |
| Audio | Chip integrated by Realtek ALC662 Up to 5.1 Channel audio-out Vista Premium compilance |
| SATA | 4 SATA ports (SATA1~4) are controlled by ICH7 North Bridge (M143D R1.0) 4 SATA ports (SATA1~4) are controlled by ICH7 North Bridge (M143B R1.0) Supports 2/4 SATA II Devices Supports storage and transfers up to 300 MB/s |
| Slots | 1 PCI Express x 16 slot 2 PCI slots, support 3.3V/5V PCI bus Interface |
| Floppy | Optional |
| Back panel | 1 PS/2 Mouse port 1 PS/2 keyboard port 1 Parallel port supporting SPP/EPP/ECP mode 1 Serial port (COM1) 1 VGA port 2 USB 2.0 ports 1 LAN jack 3 Audio jacks |
| On-Board Pinheaders | 2 USB 2.0 pinheaders 1 Front Panel Audio pinheader 1 CD-in connector |
| Form Factor | ATX (24cm x 16.8cm) |
| Mounting | 6 mounting holes |
| BIOS | The mainboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically. The mainboard provides a Desktop Management Interface (DMI) function which records your mainboard specifications. |
