PIG31U

PIG31U
LGA775 socket for latest Intel Core 2 Quad/ Core 2 Duo / Pentium (Dual-Core inside) / Pentium D / Pentium 4 / Celeron D processor

Specifications

CPU	LGA775 socket for latest Intel Core 2 Quad/ Core 2 Duo / Pentium (Dual Core inside) / Pentium D / Pentium 4 / Celeron D processor
Chipset	Intel G31 + ICH7 - North Bridge: Intel G31 - South Bridge: Intel ICH7
FSB	1333/1066/800 MHz
Memory	• DDR2 667/800 MHz SDRAM (2GB MAX) • 2 DDR2 DIMM slots (240 pin/1.8v)
VGA	• Integated Intel Graphics Media Accelerator 3100 (GMA3100) • Max Dynamic Video Memory:287MB(VISTA) /384MB(XP)
LAN	• Supports 10/100/1000 Fast Ethernet by Realtek
IEEE 1394(optional)	• Chip integrated by VIA VT 6308 • Transfer rate is up to 400Mbps
Audio	• Chip integrated by Realtek ALC655/ALC663 • Up to 5.1 Channel audio-out • Vista Premium compliance
IDE	• 1 IDE port • Supports Ultra DMA 66/100/133, PIO & Bus Master operation mode
SATA	• 2 SATA ports (SATA1~2) are controlled by ICH7 North Bridge • Supports 2 SATA II Devices • Supports storage and transfers up to 300MB/s
Slots	• 1 PCI Express x 16 slot • 1 or 2 PCI slots, support 3.3V/5V PCI bus interface
Floppy (optional)	• 1 floppy port • Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB
Back panel	• 1 PS/2 mouse port • 1 PS/2 Keyboard port • 1 Parallel port supporting SPP/EPP/ECP mode • 1 serial port (COM1) • 1 VGA port • 2 or 4 back USB 2.0 ports • 1 LAN jack • 3 audio jacks
On-Board pinheaders	• 2 USB 2.0 pinheaders • 1 Front Panel Audio pinheader • 1 CD-in connector
Fornm Factor	MATX (24cm x 16.8cm) or (21.7cm x 16.8cm)
Mounting	6 mounting holes
BIOS	Provides Plug & Play Bios which detects the peripheral devices andexpansion cards of the board automatically
DMI	It provides a Desktop Management Interface (DMI) function which records your mainboard specifications.
