PIG31L
LGA775 socket for latest Intel Core 2 Quad/ Core 2 Duo / Pentium D / Pentium HT / Pentium 4 / Celeron D processor FSB 1333 / 1066 / 800 MHz
Specifications
| CPU | LGA775 socket for latest Intel Core 2 Quad/ Core 2 Duo / Pentium (Dual Core inside) / Pentium D / Pentium 4 / Celeron D processor |
| Chipset | Intel G31 + ICH7 - North Bridge: Intel G31 - South Bridge: Intel ICH7 |
| FSB | 1333/1066/800 MHz |
| Memory | DDR2 667/800 MHz SDRAM (2GB MAX) 2 DDR2 DIMM slots (240 pin/1.8v) |
| VGA | Integated Intel Graphics Media Accelerator 3100 (GMA3100) Max Dynamic Video Memory:287MB(VISTA) /384MB(XP) |
| LAN | Supports 10/100/1000 Fast Ethernet by Realtek |
| IEEE 1394(optional) | Chip integrated by VIA VT 6308 Transfer rate is up to 400Mbps |
| Audio | Chip integrated by Realtek ALC655/ALC663 Up to 5.1 Channel audio-out Vista Premium compliance |
| IDE | 1 IDE port Supports Ultra DMA 66/100/133, PIO & Bus Master operation mode |
| SATA | 2 SATA ports (SATA1~2) are controlled by ICH7 North Bridge Supports 2 SATA II Devices Supports storage and transfers up to 300MB/s |
| Slots | 1 PCI Express x 16 slot 1 or 2 PCI slots, support 3.3V/5V PCI bus interface |
| Floppy (optional) | 1 floppy port Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB |
| Back panel | 1 PS/2 mouse port 1 PS/2 Keyboard port 1 Parallel port supporting SPP/EPP/ECP mode 1 serial port (COM1) 1 VGA port 2 or 4 back USB 2.0 ports 1 LAN jack 3 audio jacks |
| On-Board pinheaders | 2 USB 2.0 pinheaders 1 Front Panel Audio pinheader 1 CD-in connector |
| Fornm Factor | MATX (24cm x 16.8cm) or (21.7cm x 16.8cm) |
| Mounting | 6 mounting holes |
| BIOS | Provides Plug & Play Bios which detects the peripheral devices andexpansion cards of the board automatically |
| DMI | It provides a Desktop Management Interface (DMI) function which records your mainboard specifications. |
