PI945GZD
Designed for the latest Intel Core2 Duo/ Pentium(Dual-Core inside)/ Pentium D/Pentium 4/ Celeron D Processors with LGA775 Socket

Specifications

Dual Core Dual-core processor can outperform single-core processors while running at lower clock speeds and consuming less power. 64Bit Support Allows platforms to access more memory for large memory intensive applications, can see dramatic performance increases. 6 Channel Audio Chip integrated by RealtekÃ† ALC883 for Flexible 6-channel audio compliant with AC97 2.3 Dual DDR2 533 Expanding memory bandwidth to 8.53GB/s and supporting up to 4GB of memory. Dramatically shortens memory access time leads for extremely quick results. PCI Express Delivers up to a 4x increase in graphics and 2x I/O bandwidth for smooth multimedia performance. SATA II ports by ICH7 - Supports four SATA II device - Supports storage and data transfers at up to 3.0 Gb/s

CPU	LGA775 socket for latest Intel Core 2 Duo(E4400/E4300)/ Pentium(Dual- Core inside)/ Pentium D / Pentium 4 / Celeron D processor/
FSB	FSB 800/533 MHz
Chipset	Intel 945GZ & ICH7 North Bridge: Intel 945GZ South Bridge: Intel ICH7
Graphic	Integrated Intel Graphics Media Accelerator 95 (GMA950) Max Dynamic Video Memory up to 224MB(System Memory greater than or equal to 512MB)
Memory	Dual-channel DDR2 memory architecture 2 x 240-pin DDR DIMM socket support up to 2 GB Support DDR2 400/533 DDR SDRAM
Expansion Slots	1 x PCI Express x16 slot (@ x4 bandwidth) 2 x PCI slots
LAN	Realtek RTL8100C 10/100 LAN
Audio	Realtek ALC 883 6-channel audio CODEC
Storage	Support by Intel ICH7 2 x Ultra DMA100/66 devices 4 x Serial ATAII devices
Back Panel I/O Ports	1 x PS/2 keyboard & PS/2 mouse connectors 4 x USB ports 1 x Serial port (COM1) 1 x VGA port 1 x RJ45 LAN connector 1 x Audio port (3 Jacks Audio Phone)
Internal I/O Connectors & Headers	1 x 24-pin ATX Power Supply Connector & 4-pin 12V Connector 1 x FDD connector supports two 360K~2.88MB FDDs 1 x IDE connector 4 x Serial ATA connectors 1 x SPDIF out header 2 x USB 2.0 headers support additional 4 USB ports 1 x Clear CMOS header 1 x Front panel header 1 x Front panel audio header 1 x CD_in header 1 x COM2 Header CPUFAN/SYSFAN connectors
System BIOS	AMI BIOS with 4Mb SPI ROM Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI Supports ACPI revision 1.0 specification
Form Factor	Micro-ATX Size, 244mm*220mm
