PI865GVM7 V3.0
Intel Pentium 4 (775 pins) Mainboard with Intel 865GV
Specifications
| CPU | LGA775 socket for latest Intel Pentium 4/Celeron D processors |
| FSB | 800/533 MHz |
| Chipset | Intel 865GV/ICH5 |
| VGA | Embedded Intel Extreme 3D Graphics with 32M share memory |
| Memory | 3 x 184-pin DIMM sockets support 2+1 2.5V Dual channel DDR SDRAMs (DDR400/333/266) Maximum: 3GB |
| Expansion Slots | 1 x AGPUltra 3 x PCI 1 x CNR |
| LAN | Realtek RTL8100C 10/100Mbps Faster Ethernet controller |
| Audio | RTL ALC655 6-channel audio Codec Compliant with AC97 2.3 specification |
| IDE | 2 x Ultra DMA 100/66 |
| Back Panel I/O Ports | 1 x PS/2 keyboard 1 x PS/2 mouse 1 x Parallel Port 1 x Serial Port 1 x VGA Port 4 x USB 2.0 Ports 1 x RJ 45 Port 1 x Audio I/O (Line-in, Line-out and Mic-in) |
| Internal I/O Connectors & Headers | 20-pin ATX Power Supply connector 4-pin ATX 12V Power Supply connector 2 x USB header support additional 4 USB2.0 ports 2 x Serial ATA connectors 1 x Front panel switch/LED header 1 x Front panel audio header CPU / PWR/ SYS FAN headers 1 x IrDA for SIR header 1 x Speaker header 1 x CD in header 1xFloppy connector-support 360K~2.88M Byte, 3 Mode FDDs or LS120 |
| System BIOS | AMI 4Mb Flash ROM Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI Full support for ACPI revision 1.0 specification |
| Form Factor | Micro-ATX Form Factor, 244*244mm |
