PI845Z
Intel Pentium4 Socket478 / Celeron D Socket478 CPU (above 1.7 GHz Support) FSB 400/533MHZ
Specifications
| CPU | Supports Intel Celeron CPU（Frequency of 1.7GHz and above）Intel Pentium4 / Celeron D Socket478 CPU |
| FSB | 400/533MHZ |
| Chipset | North Bridge: Intel 845GV Chipset South Bridge: Intel 82801DB Chipset |
| Memory | DDR 266/333 SDRAM(2GB Max) |
| LAN | RTL8100C integrated motherboard card |
| Audio | Onboard AC 97 audio AC 97 2.1 compatible |
| IDE | 2 IDE Port Supports Ultra DMA 66/100 mode Supports PIO Bus Master operation mode |
| Floppy | 1 floppy port Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB |
| Back Panel I/O Ports | 1 Parellel port supporting SPP/EPP/ECP mode 1 PS/2 mouse port 1 PS/2 Keyboard port 1 serial port(COM1) 1 VGA port 2 USB 2.0 ports 1 RJ-45 LAN jack 3 flexible audio jacks |
| On-Board Pin headers / Connectors | USB 2.0 Pin header 1 CD-In connector 1 Front Panel Audio Pin header |
| Slots | 2 PCI |
| Form Factor | Micro ATX(24.2cmX16.9cm) |
| Mounting | 6mounting holes |
