PSM4 V5.0A
Designed for Socket 478 for intel Pentium 4 HT & Prescott processors
Specifications
| System BIOS | • AMI 2Mb Flash ROM • Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI • Full support for ACPI revision 1.0 specification |
| CPU | Socket 478 for intel Pentium 4 HT & Prescott processors |
| FSB | 800/533/400MHz |
| Chipset | SiS 661GX/964L |
| VGA | Embedded Real256E 3D Graphics with 64M share memory |
| Memory | • Maximum 2GB • 2 x 184-pin DIMM sockets support two 2.5V DDR SDRAMs (DDR400/333/266) |
| Expansion Slots | • 1 x AGP 8X • 2 x PCI Slot • 1 x CNR slot |
| Audio | C-Media CMI9739A/9761 6 Channel Audio Codec Compliant with AC97 2.3 specification |
| LAN | Realtek RTL8201BL 10/100Mbps Fast Ethernet PHY |
| Back Panel I/O Ports | • 1 x PS/2 keyboard • 1 x PS/2 mouse • 1 x Parallel Port • 1 x Serial Port • 1 x VGA port • 4 x USB 2.0 Ports • 1 x RJ 45 Port • 1 x Audio I/O (Line-in, Line-out and Mic-in) |
| IDE | 2 x UltraDMA 133/100/66 |
| Internal I/O Connectors& Headers | • 20-pin ATX power supply connector • 4-pin ATX 12V power supply connector • 2 x USB 2.0 header support additional 4 USB2.0 ports • 1 x Front panel switch/LED header • 1 x Front panel audio header • CPU/ CHS FAN headers • 1 x IrDA for SIR header • 1 x Speaker header • 1 x CD in header |
| Form Factor | • Micro-ATX Form Factor, 244*220mm |
