PVM4 V3.0
Intel Pentium 4 (478 pins) Mainboard with VIA VIA P4M800 CE/ VT8237R
Specifications
| CPU | Socket 478 for Intel Pentium 4, HT & Prescott processor |
| FSB | 800/533/400 MHz |
| Chipset | VIA P4M800 CE/ VT8237R |
| VGA | Embedded UniChrome Pro Graphics with 64M share memory |
| Memory | • 2 x 184-pin DIMM sockets support two 2.5V DDR SDRAMs (DDR400/333/266) • Maximum: 2GB |
| Expansion Slots | • 1 x AGP8X • 3 x PCI • 1 x CNR |
| LAN | VIA VT6103L 10/100Mbps Fast Ethernet PHY |
| IDE | 2 x Ultra DMA 133/100/66 |
| Back Panel I/O Ports | • 1 x PS/2 keyboard • 1 x PS/2 mouse • 1 x Parallel Port • 1 x Serial Port • 1 x VGA Port • 4 x USB 2.0 Ports • 1 x RJ 45 Port • 1 x Audio I/O (Line-in, Line-out and Mic-in) |
| Internal I/O Connectors & Headers | • 20-pin ATX Power Supply connector • 4-pin ATX 12V Power Supply connector • 2 x USB header support additional 4 USB2.0 ports • 2 x Serial ATA connectors • 1 x Front panel switch/LED header • 1 x Front panel audio header • CPU / SYS FAN headers • 1 x IrDA for SIR header • 1 x Speaker header • 1 x CD in header • 1xFloppy connector-support 360K~2.88M Byte, 3 Mode FDDs or LS120 |
| System BIOS | • AMI 4Mb Flash ROM • Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI • Full support for ACPI revision 1.0 specification |
| Form Factor | Micro-ATX Form Factor, 244*220mm |
