CKP-1000M
CKP-1000M
Specifications
| Model | CKP1000M |
| Type | ATX 12V V2.31/EPS 2.92 |
| Dimensions | W 150 x L 160 x H86mm |
| Fan Type | 140mm Fan x 1 |
| Efficiency | 80 plus Bronze / 92% Energy Efficiency |
| MTBF | 100K hrs minimum |
| Protection Features | OPP/OVP/OTP/SCP |
| Regulatory | CB/CE/TUV GS, FCC |
| Connectors | 20+4pin/CPU(4+4)x1/HDDx8/FDDx1/SATAx10/PCIE(6+2)PINx4 |
| AC Input | 100-240VAC 13A 47-63Hz |
| DC Output | +3.3V | +5V | +12V | -12V | +5Vsb ______________________________ 25.0A | 25.0A | 83.3A | 0.8A | 3.0A |
| Total Power | 1000W __________________________________ Total power on +5V & +3.3V is 130W max |
