USR1100
USR1100
Specifications
Hot-swappable dual router blades with multi-path options for high availability and load balancing
Superior performance: 1130 MBps with 8G FC ports
Power efficient: Uses < 200W
Supports LUN sizes > 2TB
Supports integrated solid state disks (SSD)
Attach servers to Fibre Channel SANs with any major iSCSI Initiator
Supports virtualization
Easy-to-use GUI for quick installation
Sophisticated web-based GUI & CLI management
| Specifications Ports Two 8Gb FC ports with fabric / loop / direct-attach modes Two 10GbE ports with hardware iSCSI acceleration Two 1GbE ports Management port: 100M / 1GbE Two USB 2.0 ports Performance iSCSI: 1130MBps max with 8Gb FC, 750MBps max with 4Gb FC Fibre Channel: 800MBps max IOps: 100K per port Server connections: Up to 32K iSCSI connections: Up to 16K iSCSI Digest at line rate 1500B frames at line rate Physical Dimensions: 1.75" x 8.25" x 18.5" or 44mm x 210mm x 470mm Full rack-width 1U chassis for two units available Horizontal or vertical mountable |
